15-75cm Underfloor Infrared Heating Film With Thermostats Black Clean Noiseless Energy Saving Easy Installation Warming Mat

Product parameter

Infrared Heating Film 220V Electric Warm Floor System

Working voltage: 200~240V 50/60Hz

Rated power: 80W/m2 ±10%

Max surface temperature: 32° C

Melting Point Film: 130 ° C

Thichness: 0.338mm

Width: 50cm

Infrared radiation: 90,4%

Wave Length: 5-20 um

Maximum film length for one row: 1100W

Electromagnetic field-almost none

400W high-power electric heating film, suitable for high-temperature products such as carbon crystal heating pad heating element materials, high-temperature yoga studios, and steam rooms.

Superiority of Heating Film Heating System:

Infrared heating is one of the healthiest and most modern method of heating, which uses a similar thermal properties as the sun itself. Infra red rays directly heat people, walls and objects, and then the air is heated from them. In traditional radiator heating it leads to heating and drying the air. Warm air flows up and first heats the top of the room and then low-lying objects, people and so on.

When using infra red heating, the air temperature is usually lower by 3-4 ° C, as in a room with traditional heating it to achieve a comparable feeling of warmth. Lowering the air temperature by 1 ° C can save up to 5-6% of energy.

Suitable for high temperature products such as carbon crystal heating pad heating element materials, high temperature yoga studios, sweat steam rooms, etc.

Packing list:

1pcs heating film

Features：

Infra panels have an efficiency of 98%, an average energy saving is 30%

Infra heating does not cause dust dispersion

It creates a healthy environment, destroys bacteria

Ensures uniform temperature in whole room

Clean, noiseless, maintenance-free operation and space-saving

Easy control and operation with thermostats

Easy installation.

Reminder:

1.Maximum film length for one row.

The maximum carrying power of the heating film is 1100W, but we can solve it in parallel.

For example,

If you buy 80W heating film, the length of a single heating film needs to be <27m,

2.When installing, do not overlap each film. Always keep 1~3cm distance between films. and keeps 10~20cm distance between the way and films.

Link method:

1. Connect the power cord to the link card

2. Half of the link card is inside the electric heating film, and the other side is outside (the copper sheet is double-layered)

3. Vigorously clamp the link card

4. Insulating mud link

Note:

1.Please allow 1-3cm error due to manual measurement. pls make sure you do not mind before you bid.

2.Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
