532nm 400mw DPSS Green Laser Module Diode Fan TTL/Analog 90~260VAC



Specification：

wavelength(nm)    532

Output power(mw)   400mw-500mw

Transverse mode    Near TEM00

Operating mode    CW

Power stability (rms, over 4 hours)    <5%

Warm-up time (minutes)    <15

M2 factor    <2.0

Beam divergence, full angle (mrad)    <2.0

Beam diameter at the aperture (mm)    ~3

Beam height from base plate (mm)    19

Polarization ratio    >100:1

Beam roundness   >90%

Operating temperature (℃)   10～35

Power supply (90-260VAC)     110(L)×92(W)×64(H)

Dimensions of Laser Head (mm)    100(L)×42(W)×55.5(H)

Modulation option    TTL/Analog modulation0-5V ( leave me message for ttl or analog in paypal when you pay. or we default mail at random)

Expected lifetime (hours)   5000

Warranty period   3+3 warranty

Note:
The modules are tested and the output power are measured by laser power meter before sending out.
Please don't compare the power of this one with a none-measured laser.
If you doubt the output, please have the laser you recieved checked by laser power meter.
If there is any problem, please feel free to contact us. We will solve the problem asap.
