This item did not include the power supply. If you want to buy the power supply, please select the one you need and click the picture.

1. What is "PoE".

A: PoE is "Power over Ethernet." A device like this one takes DC power and injects on one or both pairs of wire in the Ethernet cable. It's used to power IP cameras, VOIP phones, WiFi Access Points and other network devices

2. How long can the Ethernet cables run from the injector for a PoE phone, for example, to function reliably?

A: The cable can run for 328 feet or 100 meters.

3. I'm unclear on what power supply I will need if I wish to power an Ubiquiti 24 volt unit and a 48 volt PoE IP cameras?

A: Because of the way Ubiquiti devices work - the best method to mix UBNT and PoE cameras is to run the PoE device at 48 volts, then on a per AP basis, to step the 48 volts down to 24 volts on those ports needed. The GAF-24v15w (equivalent to the ZQ-GAF-24v15w) device works with any PoE switch and will down convert the PoE voltage (47-56 volts) to exactly 24 volts at Gigabit speeds.

4. What's the difference between active and passive PoE?

A: Active means the Power Supplying Equipment (PSE) sends a short low voltage signal to your Power Device (PD) as soon as it is connected to determine how much power it needs, then this PSE sends only that power. The most common case for this is when you have a PoE port someone could plug a laptop into by accident. The laptop isn't PoE and could be damaged by it, so, if you have an active PSE, it won't send any power to the laptop accidentally connected to it. Passive sends PoE power all the time, which works great for most PoE specific applications like cameras, WiFi access points, or a port you know only PoE devices are attached to. Both work great for the right application.

5. What does it mean when a PoE device is "passive"?

A: Passive means that the power is on all the time. An 802.3af switch keeps the power off until a compatible device is attached. A passive PoE injector or switch provides the voltage (usually 48 volts) all the time, so you should only plug in PoE capable devices.

​
